Pengembangan Aplikasi Pembeda Suara Laki-Laki dan Perempuan Berdasarkan Gender, Range Usia, Kelas Frekuensinya Berbasis FFT dan K-Means
Application Development of Male and Female Voice Differentiation Based on Gender, Age Range, Frequency Class Based on FFT and K-Means
DOI:
https://doi.org/10.33019/jurnalecotipe.v9i1.2836Keywords:
Frequency, FFT, Classification, K-Means, VoiceAbstract
It is mandatory to go through the stage of determining the type of sound in order to obtain the best choral composition. Through the FFT method with analysis using the Kmeans method, this research was successfully carried out on 30 samples of choir groups at Politeknik Negeri Balikpapan. The application is designed using the matlab gui, and is able to classify the voices of choir group based on gender, age range and sound frequency class. The test results are accurate. From the test of 30 voice samples, there were 7 adult male voices (17-45 years), and 23 types of female adult voices (17-45 years). It is broken down into 6 bass types and 1 baritone type for male gender. As for the female gender, there are 12 alto types, 2 mezzo-soprano types and 9 soprano types. The accuracy of the application is very perfect, namely 100%, so it can be concluded that the frequency range of the male voice is between 80.037 Hz – 109.266 Hz. While the frequency range of women's voices is between 108.459 Hz - 516, 677 Hz. These results are considered perfect because they have been tested by a classification process using the calculation of the input parameters using the kmeans method, although the results of the kmeans analysis have 1 error, the percentage of accuracy is still quite perfect, namely 97%. This means that the MATLAB GUI application is designed to be suitable and very useful for the world of the music industry.
Downloads
References
Andreas, "Klasifikasi Suara Manusia ke Dalam Sopran, Mezzo Sopran, Alto, Tenor, Bariton, Bass dengan Self Organizing Map", Jurnal Informatika, 11(1), 2015.
S. B. Bhaskoro, "Aplikasi Pengenalan Gender Menggunakan Suara", Seminar Nasional Aplikasi Teknologi Informasi / Snat 2012. Jogjakarta.
A. S. Irtawaty, "Implementasi Metode Fast Fourier Transform / FFT Dalam Mengklasifikasikan Suara Pria dan Wanita di Laboratorium Jurusan Teknik Elektro Poltekba", Jurnal Teknologi Terpadu, 7(2), 70-75, 2019.
A. S. Irtawaty, "Peningkatan Performansi Aplikasi Pembeda Suara Laki-Laki dan Perempuan Berdasarkan Frekuensi dengan Menggunakan Metode Fuzzy Logic", JurnalEcotipe, 7(1), 1-6, 2020.
J. F. Dadang Gunawan, "Pengolahan Sinyal Digital dengan Pemrograman Matlab 1st Ed., Jogjakarta: Graha Ilmu, 2012.
Ade Royani, "Mengidentifikasi Sinyal Suara Manusia Menggunakan Metode FFT Berbasis Matian", Journal of Information, Information System, Software Engineering and Applications, Volume 1 Nomor 2. pp 042-050, 2019.
Y. S. Ronaldo, "Simulasi Sistem Pengacau Sinyal Dengan Metode FFT (Fast Fourier Transform)", e-Journal Teknik Elektro dan Komputer, 2014.
W. Rahim, "Analisis Spektrum Suara Manusia Berdasarkan Jenis".
Nailul Sudah, "Katering Suara Berdasarkan Gender Menggunakan Algoritma K-Means Dari Hasil Ekstradisi FFT (Fast Fourier Transform)", Journal Ilmiah : SOULMATH, Volume 6 Nomor 1. Hal. 47-58, 2018.
B. W. Prasetya, "Identifikasi Suara Pria Dan Wanita Berdasarkan Frekuensi Suara", 2011.
