Reliability Analysis of Steam Turbine Instrumentation Using the Failure Mode and Effect Analysis (FMEA) Method at PT. PLN Nusantara Power UP Tenayan
Abstract
PT. PLN Nusantara Power Unit Generation Tenayan is a company operating in the Steam Power Plant sector in Pekanbaru, Indonesia. One of the main components of a steam power plant (PLTU) is a steam turbine. A steam turbine is a machine that functions to convert kinetic energy into electrical current. Operational failures are often caused by less than optimal instrumentation in the steam turbine. This research uses the failure mode and effect analysis (FMEA) method with the aim of identifying the type of failure, the cause of the failure, the effect of the failure, and determining the RPN value. The analysis results from this research show that the turbine instrumentation components still meet performance standards because the risk priority number (RPN) value is less than 200. The conclusion from this research is that errors in steam turbine instrumentation are inaccurate sensor readings, switches cannot deactivate the equipment, and readings control room does not match local readings, the instrumentation component with the highest risk priority number (RPN) is the solenoid valve with a value of 140, and the instrumentation component with the lowest risk priority number (RPN) is the pressure indicator with a value of 30. The component given top priority in action The recommendation is for the solenoid valve component, namely to carry out maintenance every 6 months and add an overspeed protection system
Downloads
References
R. Apriandi and A. Mursadin, “Steam Turbine Performance Analysis Based on Performance Test of Pt Pt. Indocement P-12 Tarjun,” Sci. J. Mech. Eng. Kinemat. , vol. 1, no. 1, pp. 37–46, 2016, doi: 10.20527/sjmekinetika.v1i1.26.
A. Rahman Hafiz, A. Nuramal, and N. Iman Supardi, "Analysis Of Electricity Production In Minihydro Power Plant (PLTM) Analysis of Electricity Production in Mini Hydro Power Plants (PLTM)," J. Rekayasa Mek. , vol. 6, no. 1, p. 2022, 2022.
PRH Marpaung, H. Eteruddin, and D. Setiawan, "Study of Load Changes on AVR Performance on Synchronous Generator Unit 2 of PT Steam Power Plant (PLTU). Ubjom Tenayan Raya,” Semin. Nas. Science Works. Multidisciplinarity , vol. 1, no. 1, pp. 96–109, 2021.
E. Team, “20. JT, Vol.14, No.2, Transient Analysis of the Riau 150 kV Transmission System After the Operation of PLTU Tenayan Raya, AiO”.
Rahayu Deny Danar and Alvi Furwanti Alwie, AB Prasetio, R. Andespa, PN Lhokseumawe, and K. Introduction, "Final Assignment Final Project," J. Ekon. Vol. 18, Number 1 March 201 , vol. 2, no. 1, pp. 41–49, 2020.
R. Djafar, B. Liputo, and Y. Djamalu, "Determining Energy Losses in Main Components of PLTU Using Cylcle Tempo Simulation," J. Teknol. Pertan. Gorontalo , vol. 7, no. 1, pp. 36–40, 2022, doi: 10.30869/jtpg.v7i1.911.
J. Permana and I. Kurniawan, “Calculation analysis of generated turbine power and steam turbine efficiency in Unit 1 and Unit 2 at Pt. Indonesia Power Uboh Ujp Banten 3 Lontar," Mot. Burn J. Tech. Machines , vol. 1, no. 2, pp. 1–8, 2017, doi: 10.31000/mbjtm.v1i2.731.
H. Santoso, "Optimization to Produce Ideal Efficiency of Steam Turbines for Biomass Power Plants with a Capacity of 20 MW," STRING (Unit for Research and Innovation Technology , vol. 3, no. 2, p. 181, 2018, doi : 10.30998/string.v3i2.3044.
D. Reza and G. Ramayanti, "Damage Analysis of Mandrel Tension Reel Machine Using the Failure Mode and Effect Analysis (FMEA) Method," no. November, pp. 190–195, 2017.
Suseno and SI Kalid, "Quality Control of Leather Bag Product Defects Using Failure Mode and Effect Analysis (Fmea) and Fault Tree Analysis (Fta) Methods at Pt Mandiri Jogja Internasional," J. Cakrawala Ilm. , vol. 1, no. 6, pp. 1307–1320, 2022, doi: 10.53625/jcijurnalcakrawalailmiah.v1i6.1131.
I. Nurdiansah, Marno, and A. Santosa, "Damage Analysis of the Al Pin 350 Lathe Machine Using the Failure Mode and Effect Analysis (FMEA) Method," J. Ilm. Educator's Ride. , vol. 8, no. 1, pp. 704–708, 2022, doi: 10.5281/zenodo.5921782.
SH Al Hakiki and D. Dwisetiono, "Analysis of Lubricating Systems Using the FMEA Method to Determine System Failures," Zo. Sea J. Inov. Science and Technology. To the sea. , vol. 2, no. 3, pp. 99–105, 2021, doi: 10.62012/zl.v2i3.18594.
W. Amalia, D. Ramadian, and SN Hidayat, "Damage Analysis of Palm Oil Mill Sterilizer Machines Using Failure Modes and Effect Analysis (FMEA)," J. Tek. Ind. J. Has. Researcher. and Science Works. in Bid. Tech. Ind. , vol. 8, no. 2, p. 369, 2022, doi: 10.24014/jti.v8i2.19179.
SB Marpaung, DAA Ritonga, and A. Irwan, "Analysis of Risk Priority Number (RPN) on the Reliability of Thresher Machine Components Using the Fmea Method at Pt . 9, no. 2, pp. 74–81, 2021, doi: 10.35447/jitekh.v9i2.427.
M. Rinoza and F. Ahmad Kurniawan, "Rpn (Risk Priority Number) Analysis of the Reliability of Double Screw Compressor Machine Components Using the Fmea Method at the Pt Cement Factory. Xyz,” Print) Bul. Main Tech. , vol. 17, no. 1, pp. 1410–4520, 2021.
TJ Wibowo, TS Hidayatullah, and A. Nalhadi, "Maintenance Analysis on Lathes Using the Reliability Centered Maintenance (RCM) Approach," J. Rekayasa Ind. , vol. 3, no. 2, pp. 110–120, 2021, doi: 10.37631/jri.v3i2.485.
